TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA1180XZH5 |
|
Overall Dimensions |
mm |
8250×2460×2840 |
|
|
GVW |
kg |
18000approximate |
|
|
Curb Weight |
7875approximate |
||
|
Rated Load |
10000pproximate |
||
|
Front/Rear Hanging |
mm |
1430/1820 |
|
|
Approach/Departure Angle |
° |
19/13 |
|
|
Leaf Spring |
pcs |
8/10+8 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
DFL1140B10 |
|
|
Manufacturer |
|
Dongfeng Motor Co., Ltd |
|
|
Wheel Base |
mm |
5000 |
|
|
Tire Specification |
inch |
255/70 R22.5 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
ISB 180 50 (Euro V) |
|
Manufacturer |
|
Dongfeng Cummins Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
180 |
|
|
Displacement |
ml |
5900 |
|
|
Emission Standard |
|
Euro V |
|
|
Gearbox |
No. of Gears |
|
Manual 6-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
One and a half rows |
|
|
Equipment |
Carriage size:6000*2450*500(mm) |
||
|
|
|
||
