TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5180JSQ6 |
|
Overall Dimensions |
mm |
9000*2550*3850 |
|
|
GVW |
kg |
18000 approximate |
|
|
Curb Weight |
10800 approximate |
||
|
Rated Load |
7000approximate |
||
|
Front/Rear Hanging |
mm |
1450/2550 |
|
|
Approach/Departure Angle |
° |
16/10 |
|
|
Leaf Spring |
pcs |
8/10+8 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
DFH1180EX8 |
|
|
Manufacturer |
|
Dongfeng Commercial Vehicle Co., Ltd |
|
|
Wheel Base |
mm |
5000 |
|
|
Tire Specification |
inch |
10.00R20 18PR |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
B6.2NS6B230 (Euro VI ) |
|
Manufacturer |
|
Dongfeng Cummins Engine Co.,Ltd. |
|
|
Engine Horsepower |
hp |
230 |
|
|
Displacement |
ml |
6200 |
|
|
Emission Standard |
|
Euro VI |
|
|
Gearbox |
No. of Gears |
|
Manual 8-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
One and a half rows |
3. CRANE SPECIFICATION :
|
Crane model |
Lifting height |
Working radius |
Installation Space |
|
SQS125K |
10.5m |
8.7m |
950mm |
