TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
|
Overall Dimensions |
mm |
10900*2550*3895 |
|
Curb Weight |
kg |
16140approximate |
|
|
Load Weight |
20000pproximate |
||
|
Axle load |
kg |
7500/10000/10000 |
|
|
Front/Rear Hanging |
mm |
1460/3240 |
|
|
Approach/Departure Angle |
° |
18/7 |
|
|
Leaf Spring |
pcs |
9/12 |
|
|
Drive Wheel |
|
6*4 |
|
|
Chassis Model |
|
SX5258ZYSMR |
|
|
Manufacturer |
|
Shaanxi Automobile Group Co., Ltd |
|
|
Wheel Base |
mm |
4375+1400 |
|
|
Tire Specification |
inch |
12R22.5 18PR |
|
|
No. of Tires |
pcs |
10+1 spare |
|
|
Engine |
Engine Type |
|
ISL325 50 |
|
Manufacturer |
|
Dongfeng Cummins Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
325 |
|
|
Displacement |
ml |
8880 |
|
|
Emission Standard |
|
Euro VI |
|
|
Gearbox |
No. of Gears |
|
Manual 10-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
Single row and s sleeper |
|
|
Equipment |
Carriage size:7200*2500*1150(mm) |
||
|
The crane is XCMG 6.3 ton four section folding arm crane,the crane is installed at the rear of the carriage. The crane is operated by the wireless remote control. Working radius :10.4 meters. Working height: 13meters |
|||
