2. TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
|
Overall Dimensions |
mm |
6960*2200*2810 |
|
GVW |
kg |
11300 approximate |
|
|
Curb Weight |
6050 approximate |
||
|
Rated Load |
4800 approximate |
||
|
Max Speed |
km/h |
95 |
|
|
Leaf Spring (F/R) |
pcs |
8/10+7 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
EQ1125SJ |
||
|
Manufacturer |
Dongfeng Commercial Automobile Co., Ltd. |
||
|
Wheel Base |
mm |
3800 |
|
|
Tire Specification |
inch |
8.25R16 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
ISF3.8S5154 4 stroke water cooling , direct Injection |
|
|
Manufacturer |
Foton Cummins Engine Co., Ltd. |
||
|
Engine Fuel |
|
Diesel |
|
|
Engine Horsepower |
hp |
154 |
|
|
Displacement |
ml |
3800 |
|
|
Emission Standard |
|
Euro V |
|
|
Cab |
Allow passenger |
|
3+3 |
|
Row |
|
Double |
|
|
Water tanker |
Capacity |
L |
3500 |
|
Fire fight pump |
Type |
Centrifugal Pump |
|
|
Model |
CB10/40 |
||
|
Pressure |
Mpa |
1.0 |
|
|
Flow Rate |
L/S |
40 |
|
|
Section depth |
m |
>7 |
|
|
Section time |
Second |
<30 |
|
|
Delivery Outlet |
mm |
65 |
|
|
Fire fighting gun |
Model |
|
PS30 |
|
Pressure |
Mpa |
1 |
|
|
Flow Rate |
L/S |
20 |
|
|
Range distances |
m |
>55 |
|
|
Rotary angle |
deg |
360 |
|
|
Pipeline system |
Inner inlet pipe |
Φ100mm one inlet pipe , from tanker to fire flighting pump . WithΦ100mm butterfly valve connect water tanker and water pump . |
|
|
Exterior inlet pipe |
Both sides of the pump inlet pipeΦ100mm, get out of straw, pull the tooth and tube within the interface, ( plug seal ) ; both sides of the pump directional drawing water suction pipe . Φ100×2m (4 pieces ) |
||
|
Equipment |
1. 80W alarm light Rotating lights switch PTO Control Switch One manhole Install overflow valve Fluid level indicator Effluent discharge inlet Long rows of lights Fire ground Light ( 12V ,60W) |
||
Parts List
|
No. |
Name |
Size |
Unit |
QTY |
|
1 |
Suction Pipe |
Φ100×2000mm |
|
4 |
|
2 |
water-strainer |
FLF100 |
|
1 |
|
3 |
Water spilt |
FFS80 |
|
1 |
|
4 |
Water collector |
FJ100-2B1-1.6 |
|
1 |
|
5 |
Fire hose |
Φ65×20m |
roll |
6 |
|
Fire hose |
Φ80×20m |
roll |
6 |
|
|
6 |
Interface |
KT100 |
|
1 |
|
7 |
Hose bandage |
FP470 |
|
4 |
|
8 |
Hose strap |
FG600 |
|
4 |
|
9 |
Hose protector |
FH80 |
|
2 |
|
10 |
Overground hydrant wrench |
FB450 |
|
2 |
|
11 |
Underground hydrant wrench |
FBA800 |
|
1 |
|
12 |
suction wrench |
FS100 |
|
4 |
|
13 |
Powder-type extinguisher |
MFZ2 |
|
1 |
|
14 |
fire bucket |
|
|
1 |
|
15 |
water-stream nozzle |
QZG19 |
|
2 |
|
16 |
Multifunctional water nozzle |
QZW65 |
|
2 |
|
17 |
Firemen’s axe |
GFP890 |
|
2 |
|
18 |
fire shovel |
2# |
|
2 |
|
19 |
Crowbar |
GT06 |
|
2 |
|
20 |
Fire Hook |
|
|
1 |
|
21 |
Tool box |
|
|
1 |
|
22 |
fire extinguisher |
|
|
1 |
