TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5180ZYS5 |
|
Overall Dimensions |
mm |
8650*2550*3300 |
|
|
Curb Weight |
kg |
8800approximate |
|
|
Rated Load |
10800approximate |
||
|
Garbage box capacity |
m³ |
15 |
|
|
Compaction ratio |
T/m³ |
0.75 |
|
|
Front/Rear Hanging |
mm |
1260/2340 |
|
|
Approach/Departure Angle |
° |
19/8 |
|
|
Leaf Spring |
pcs |
8/10+7 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
EQ1140B10 |
|
|
Manufacturer |
|
Dongfeng Automobile Co., Ltd |
|
|
Wheel Base |
mm |
4700 |
|
|
Tire Specification |
inch |
10.00R20 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
ISB210 50 (Euro V ) |
|
Manufacturer |
|
Dongfeng Cummins Engine Co.,Ltd. |
|
|
Engine Horsepower |
hp |
210 |
|
|
Displacement |
ml |
5900 |
|
|
Emission Standard |
|
Euro V |
|
|
Gearbox |
No. of Gears |
|
Manual 6-speed with overdrive |
|
Cab |
passengers |
|
3 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
One and a half rows |
|
|
Other |
Electric air conditioning, regular air filter, metal bumper, large capacity battery, Dongfeng logo |
||
|
Equipment |
Garbage container volume:18000L |
||
|
Garbage loading method: Garbage bin lifting device, capable of lifting 120L or 240L garbage bins |
|||
|
Hydraulic system control: manual control, electronic control, wireless remote control |
|||
|
Sewage tank capacity:150L+150L |
|||
|
Material of garbage container : manganese steel |
|||
|
Thickness of garbage container :Bottom plate:5mm;side plate: 5mm; top plate:5mm |
|||
|
Body exterior color: customizable according to customer requirements |
|||
