TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5070ZYSD6 |
|
Overall Dimensions |
mm |
6763×2250×2570 |
|
|
Curb Weight |
kg |
5880approximate |
|
|
Rated Load |
5040approximate |
||
|
Volume |
L |
7200pproximate |
|
|
Front/Rear Hanging |
mm |
1055/2052 |
|
|
Approach/Departure Angle |
° |
28/12 |
|
|
Leaf Spring |
pcs |
6/6+5 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
EQ1075SJ3CDF |
|
|
Manufacturer |
|
Dongfeng Motor Group Co., Ltd |
|
|
Wheel Base |
mm |
3308 |
|
|
Tire Specification |
inch |
7.50R16 14PR |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
CA4DB1-13E6 (Euro VI) |
|
Manufacturer |
|
China FAW Group Co., Ltd |
|
|
Engine Horsepower |
hp |
130 |
|
|
Displacement |
ml |
2207 |
|
|
Emission Standard |
|
Euro VI |
|
|
Gearbox |
No. of Gears |
|
Manual 6-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
Single row |
|
|
Other |
Electric air conditioning, regular air filter, metal bumper, large capacity battery, Dongfeng logo |
||
|
Equipment |
Garbage bin volume:72000L |
||
|
Hydraulic system control: manual control |
|||
|
Garbage loading method: rear hanging bucket flip frame (hanging 240-liter garbage bin). |
|||
|
Sewage tank capacity: 100L+100L |
|||
|
Material of garbage bin: manganese steel |
|||
|
Thickness of garbage bin:Bottom plate:5mm;side plate: 4mm; top plate: 4mm |
|||
|
Body exterior color: customizable according to customer requirements |
|||
