ITEM

PARAMETER

UNIT

DATA

Whole Vehicle

Vehicle Model

SA5254ZYS5

Overall Dimensions

mm

10600*2550*3450

Curb Weight

kg

17150approximate

Rated Load

17250pproximate

Front/Rear Hanging

mm

1450/2705

Approach/Departure Angle

 °

25/14

Leaf Spring

pcs

9/10

Drive Wheel

6*4

Chassis Model

SX5258ZYSMR434C

Manufacturer

Shaanxi Commercial Automobile Co., Ltd.

Wheel Base

mm

4375+1400

Tire Specification

inch

12R22.5

No. of Tires

pcs

10+1 spare

Engine

Engine Type

ISL 325 50(EuroV )

Manufacturer

     SHACMAN Cummins Engine Co.,Ltd.

Engine Horsepower

hp

325

Displacement

ml

8880

Emission Standard

Euro V

Gearbox

No. of Gears

Manual 10-speed with overdrive

Cab

passengers

3

steering wheel

LHD

ROW

One and a half rows

Other

Hydraulic main seat, four point hydraulic suspension cab, electric window shaker, manual flipping, electric air conditioning, telescopic shaft control, ordinary air filter, metal bumper, two-stage boarding pedal, 180Ah maintenance-free battery, SHACMAN logo, all English logo, remote accelerator controller

Equipment

Garbage container volume:23000L

Rear garbage loader volume:1500L

Hydraulic system control: electric control and manual control

Sewage tank capacity: 200L

Material of garbage bin: manganese steel

Thickness of garbage bin:Bottom plate:8mm;side plate: 5mm; top plate: 6mm

Body exterior color: customizable according to customer requirements
