ITEM

PARAMETER

UNIT

DATA

Whole Vehicle

Vehicle Model

SA5259GJB6

Overall Dimensions

mm

9400X2500X3780

GVW

kg

25000 approximate

Curb Weight

12500 approximate

Rated Load

12370approximate

Front/Rear Hanging

mm

1540/1870

Approach/Departure Angle

 °

16/20

Leaf Spring

pcs

10/12

Drive Wheel

6*4

Chassis Model

SX5259GJB6U364C

Manufacturer

Shaanxi Automobile Group

Wheel Base

mm

3775+1400

Tire Specification

inch

385/65R22.5

315/80R22.5

No. of Tires

pcs

10+1 spare

Engine

Engine Type

X12EVIE410 (Euro VI)

Manufacturer

  Xi'an Cummings  Engine Co., Ltd

Engine Horsepower

hp

410

Displacement

ml

11800

Emission Standard

Euro VI

Gearbox

No. of Gears

AMT 13-speed with overdrive

Cab

passengers

2

steering wheel

LHD

ROW

One and a half rows

Equipment

Tank volume:10m³
