2. TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5250GJB5 |
|
Overall Dimensions |
mm |
9900X2500X3860 |
|
|
Curb Weight |
kg |
11900 approximate |
|
|
Rated Load |
22000approximate |
||
|
Tank volume |
㎥ |
10 |
|
|
Front/Rear Hanging |
mm |
1450/1870 |
|
|
Approach/Departure Angle |
° |
||
|
Leaf Spring |
pcs |
9/12 |
|
|
Drive Wheel |
|
6*4 |
|
|
Chassis Model |
|
DFH3250A1 |
|
|
Manufacturer |
|
Dongfeng Commercial Vehicle Co., Ltd |
|
|
Wheel Base |
mm |
3800+1350 |
|
|
Tire Specification |
inch |
12.00R20 |
|
|
No. of Tires |
pcs |
10+1 spare |
|
|
Engine |
Engine Type |
|
ISL9.5-340E53A (Euro V) |
|
Manufacturer |
|
Dongfeng Cummins Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
340 |
|
|
Displacement |
ml |
9460 |
|
|
Emission Standard |
|
Euro V |
|
|
Gearbox |
No. of Gears |
|
Manual 10-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
One and a half rows |
