ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5145GXW |
|
Overall Dimensions |
mm |
7450×2420×3260 |
|
|
Tank capacity |
㎥ |
Sewage tank：6 |
|
|
Clear water tank：2 |
|||
|
Curb Weight |
Kg |
8380approximate |
|
|
Load Weight |
8000approximate |
||
|
Front/Rear Hanging |
mm |
1180/2470 |
|
|
Approach/Departure Angle |
° |
21/14 |
|
|
Leaf Spring |
pcs |
8/10+7 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
EQ1145SJ |
|
|
Manufacturer |
|
Dongfeng Automobile Co., Ltd |
|
|
Wheel Base |
mm |
3800 |
|
|
Tire Specification |
inch |
8.25R16 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
ISF3.8S5154 (Euro V) |
|
Manufacturer |
|
Dongfeng Cummins Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
154 |
|
|
Displacement |
ml |
3760 |
|
|
Emission Standard |
|
Euro V |
|
|
Gearbox |
No. of Gears |
|
Manual 6-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
Single row |
|
|
Equipment |
Tank volume: 8000L, clean water tank:2000L;sewage tank:6000L;Thickness: 5mm. |
||
|
High pressure pump: pressure of 20Mpa; Flow rate 215L/min. |
|||
|
Suction pump: SK-15 water ring vacuum suction pump,, vertical suction depth up to 10 meters, horizontal suction distance not less than 50 meters. |
|||
|
Roll: can wrap 60 meters of high-pressure pipes, hydraulic control, can rotate 250 degrees |
|||
|
High pressure hose: A domestically produced high-quality DN19 high-pressure hose specifically designed for sewer dredging, which is resistant to high pressure, lightweight, has low friction resistance, and strong scratch resistance. Standard configuration pipe length: 60m |
|||
|
Suction pipe: PVC102mm vacuum suction pipe, length 7 m |
|||
|
Nozzle: Standard includes 1 diamond shaped nozzle, 2 mushroom nozzles, and 1 cleaning spray gun. |
|||
