ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5140GPSD6 |
|
Overall Dimensions |
mm |
7400×2450×3000 |
|
|
Curb Weight |
kg |
5550approximate |
|
|
Rated Load |
10000approximate |
||
|
Tank volume |
L |
10000approximate |
|
|
Front/Rear Hanging |
mm |
1180/2420 |
|
|
Approach/Departure Angle |
° |
21/10 |
|
|
Leaf Spring |
pcs |
8/10+7 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
||
|
Manufacturer |
|
Dongfeng Motor Co., Ltd |
|
|
Wheel Base |
mm |
3800 |
|
|
Tire Specification |
inch |
8.25R20 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
D4.0NS6B195 (Euro V ) |
|
Manufacturer |
|
Dongfeng Cummins Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
195 |
|
|
Displacement |
ml |
4000 |
|
|
Emission Standard |
|
Euro VI |
|
|
Gearbox |
No. of Gears |
|
Manual 8-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
Singe row |
|
|
Other |
Electric air conditioning, regular air filter, metal bumper, large capacity battery, Dongfeng logo |
||
|
Equipment |
Water tank:10000L |
||
|
The watering width is 14 meters, and the range of the rear watering gun is 28 meters. Install a 30 meter fog cannon with diesel power. |
|||
