ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5252GPSD6 |
|
|
Overall Dimensions |
mm |
10600*2550*3200 |
|
|
Curb Weight |
kg |
11000approximate |
|
|
Rated Load |
|
20000approximate |
|
|
Tank volume |
L |
20000approximate |
|
|
Front/Rear Hanging |
mm |
1480/2880 |
|
|
Approach/Departure Angle |
° |
20/10 |
|
|
Leaf Spring |
pcs |
9/10 |
|
|
Drive Wheel |
|
6*4 |
|
|
Chassis Model |
|
DFH1250D4 |
|
|
Manufacturer |
|
Dongfeng Automobile Co., Ltd. |
|
|
Wheel Base |
mm |
4350+1350 |
|
|
Tire Specification |
inch |
11.00R20 |
|
|
No. of Tires |
pcs |
10+1 spare |
|
Engine |
Engine Type |
|
D6.7NS6B320 (EuroVI ) |
|
|
Manufacturer |
|
Dongfeng Cummins Engine Co.,Ltd. |
|
|
Engine Horsepower |
hp |
320 |
|
|
Displacement |
ml |
6700 |
|
|
Emission Standard |
|
Euro VI |
|
Gearbox |
No. of Gears |
|
Manual 9-speed with overdrive |
|
Cab |
passengers |
|
2 |
|
|
steering wheel |
|
LHD |
|
|
ROW |
|
One and a half rows |
|
Other |
Airbag main seat, electric doors and windows, manual flipping, electric air conditioning, regular air filter, metal bumper, two-stage boarding pedal, large capacity battery, Dongfeng logo, all English logo, remote accelerator controller |
||
|
Equipment |
Water tank:20000L |
||
|
|
The watering width is 14 meters, and the range of the rear watering gun is 28 meters. |
||
