ITEM

PARAMETER

UNIT

DATA

Overall Dimensions

mm

10920*2550*2960

Rated Load

 kg

12600aproximate

Max  Load

 15000aproximate

Axle load

7000/10000

Front/Rear Hanging

mm

1400/3250

Approach/Departure Angle

 °

23/9

Leaf Spring

pcs

9/10

Drive Wheel

6*4

Chassis Model

DFL1250A13

Manufacturer

Dongfeng Commercial Vehicle Co., Ltd

Wheel Base

mm

5700+1350

Tire Specification

inch

11.00R20

No. of Tires

pcs

10+1 spare

Engine Type

ISD270 50(Euro V)

Manufacturer

     Dongfeng Cummins Engine Co., Ltd

Engine

Engine Horsepower

hp

270

Displacement

ml

6700

Emission Standard

Euro V

No. of Gears

Manual 9-speed with overdrive

passengers

2

Gearbox

steering wheel

LHD

Cab

ROW

One and a half rows

Equipment

Plate size：10000*2500（mm）

15 ton upper load, 12 ton winch, 25 meter steel wire rope, dual side linkage operation, rear support arm towing 12 tons, with optional patterned and pressed plates, imported valve, equipped with a set of auxiliary carts, yellow electronic alarm lights, four bundlers, one pair of rotating cylinders, one pair of L-shaped holding tires, and other standard configurations
