TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5090TQZ6 |
|
Overall Dimensions |
mm |
6200X2500X2450 |
|
|
GVW |
kg |
9000approximate |
|
|
Curb Weight |
2800approximate |
||
|
Rated Load |
6000approximate |
||
|
Front/Rear Hanging |
mm |
1110/1285 |
|
|
Approach/Departure Angle |
° |
16/13 |
|
|
Leaf Spring |
pcs |
3/5+2 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
||
|
Manufacturer |
|
Beiqi Foton Motor Co., Ltd |
|
|
Wheel Base |
mm |
3600 |
|
|
Tire Specification |
inch |
7.00R16 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
F2.5NS6B160(Euro VI) |
|
Manufacturer |
|
Beijing Foton Cummins Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
160 |
|
|
Displacement |
ml |
2498 |
|
|
Emission Standard |
|
Euro VI |
|
|
Gearbox |
No. of Gears |
|
Manual 8-speed with overdrive |
|
Cab |
passengers |
|
3 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
One and half Row |
|
|
Other |
Air conditioning, directional assistance, Oil brake,warning lights |
||
|
Special Function |
1. Suitable for passenger vehicle road rescue 2. Flat-bed size(L*W):6200*2450(mm) 3. Flat-bed capacity :6T 4. Rear support arm lifting weight: 4T 5. Hydraulic winch: 6T 6. Hydraulic winch steel wire rope: 25 m 7.Warning lights and loudspeakers |
||
