TECHNOLOGY PARAMETER
|
ITEM |
PARAMETER |
UNIT |
DATA |
|
Whole Vehicle |
Vehicle Model |
|
SA5120TQZQ6 |
|
Overall Dimensions |
mm |
8490X2500X2450 |
|
|
GVW |
kg |
12000approximate |
|
|
Curb Weight |
6800approximate |
||
|
Rated Load |
5000approximate |
||
|
Front/Rear Hanging |
mm |
||
|
Approach/Departure Angle |
° |
17/15 |
|
|
Leaf Spring |
pcs |
8/10+6 |
|
|
Drive Wheel |
|
4*2 |
|
|
Chassis Model |
|
||
|
Manufacturer |
|
Qingling（ISUZU） Motors Co., Ltd. |
|
|
Wheel Base |
mm |
4475 |
|
|
Tire Specification |
inch |
8.25R20 |
|
|
No. of Tires |
pcs |
6+1 spare |
|
|
Engine |
Engine Type |
|
4HK1-TCG61(Euro VI) |
|
Manufacturer |
|
ISUZU (China) Engine Co., Ltd |
|
|
Engine Horsepower |
hp |
190 |
|
|
Displacement |
ml |
5193 |
|
|
Emission Standard |
|
Euro VI |
|
|
Gearbox |
No. of Gears |
|
Manual 6-speed with overdrive |
|
Cab |
passengers |
|
3 |
|
steering wheel |
|
LHD |
|
|
ROW |
|
Single Row |
|
|
Other |
Air conditioning, directional assistance, Oil brake,warning lights |
||
|
Special Function |
1. Suitable for passenger vehicle road rescue 2. Flat-bed size(L*W):6600*2450(mm) 3. Flat-bed capacity :5T 4. Rear support arm lifting weight: 4T 5. Hydraulic winch: 5T 6. Hydraulic winch steel wire rope: 25 m |
||
